Mango Drying Machine
Efficient Drying Equipment
High-quality Dried Mangoes
Versatile Drying Capabilities
All-in-one Functionality
Durable and Well-insulated Design
User-friendly Control System
Heat source can be freely chosen according to the local situation. Wood, coal, biomass granules, steam, natural gas, diesel, air chamber (electricity), etc.
Product Description
Mango Heat Pump Drying Room is a highly efficient drying equipment specifically designed for mangoes. It ensures the production of high-quality dried mangoes by utilizing advanced heat pump technology. The drying room offers versatile capabilities, allowing it to accommodate various drying needs. With its all-in-one functionality, the mango heat pump drying room provides a complete solution for the drying process.
Ⅰ.Construction Of The Mango Drying Room:
Drying machine is made of heating system (including but not limited to coal/firewood, wooden pellets, gas, biogas, steam, liquid fuel, electricity etc ),drying room, certain number movable carts inside to load drying materials.There are usually 2/4/6/8/10/12/18/24 movable carts inside based on different capacity.
Ⅱ.Air Source Heat Pump Drying Principle:
First, push carts with loaded fresh materials inside, then setting drying temperature, humidity and time. After hot air generated from heating system, anti-high temperature & humidity fans will circulate hot air across fresh materials laying on each tray of carts evenly inside drying room, humidity emitting fans start to work when the moisture reaches setting data. During drying process, when temperature reaches setting data, heat system will automatically shut down to achieve energy-saving effects. After well-drying, pull out carts containing dried materials. And prepare for next batch drying. Clients are suggested to have double quantity of carts to avoid energy waste during fresh materials loading time.
Ⅲ.Features And Benefits Of Mango Drying Machine:
- 01Efficient Drying Equipment: The mango drying machine is highly efficient, ensuring optimal drying performance.
- 02High-quality Dried Mangoes: The machine preserves the color, flavor, and texture of mangoes, resulting in high-quality dried mangoes.
- 03Versatile Drying Capabilities: The equipment can be used to dry a variety of materials, expanding its applications beyond mangoes.
- 04All-in-one Functionality: The machine combines drying, moisture removal, and other functions into a single unit, simplifying the drying process.
- 05User-friendly Control System: The equipment features a user-friendly control system, allowing for easy operation and parameter setting.
- 06Durable and Well-insulated Design: The mango drying machine is built with a durable and well-insulated design, promoting even heating and maintaining energy efficiency.
Technical Parameters
| Model | Length*width*height(mm) | Heat pump power (P) (Copeland compressor) |
Number of small carts (vehicles) |
Number of pallets (pcs) |
Number of fans (units) |
Pallet size 10 layers(mm) |
Approximate drying yield/ batch (kg) |
| 4-car side air supply | 4500*2300*2100 | 3 | 4 | 40 | 2 | 1400*900 | 800 |
| 4 car rear air supply | 6000*1800*2500 | 7 | 4 | 40 | 4 | 1400*900 | 800 |
| 6 car rear air supply | 6500*2300*2500 | 7 | 6 | 60 | 6 | 1400*900 | 1200 |
| 8 car rear air supply | 8000*2300*2500 | 7 | 8 | 80 | 6 | 1400*900 | 1600 |
| 10 car rear air supply | 7000*3300*2500 | 15 | 10 | 100 | 8 | 1400*900 | 2000 |
| 12 car rear air supply | 8000*3300*2500 | 15 | 12 | 120 | 8 | 1400*900 | 2400 |
| 18 car rear air supply | 8000*4800*2600 | 2*15 | 18 | 180 | 10 | 1400*900 | 3600 |
| 24 car rear air supply | 8000*6200*2600 | 2*15 | 24 | 240 | 12 | 1400*900 | 4800 |
| The above parameters are for reference only and capacity is specific to mango to be dried. | |||||||
