Pineapple Drying Machine
All-in-one Design
Independent Operation
Versatile Application
Customizable Options
Durable and Hygienic Construction
Automated control
Excellent Drying Performance
Heat source can be freely chosen according to the local situation. Wood, coal, biomass granules, steam, natural gas, diesel, air chamber (electricity), etc.
Product Description
The pineapple dryer utilizes a hot air circulation system to extract moisture from the pineapple slices, resulting in a desirable texture and extended shelf life. With precise temperature control and energy-efficient operation, the Pineapple Dryer offers a reliable and effective solution for commercial pineapple processing.
Ⅰ.Construction Of The Pineapple Dryer:
Drying machine is made of heating system (including but not limited to coal/firewood, wooden pellets, gas, biogas, steam, liquid fuel, electricity etc ),drying room, certain number movable carts inside to load drying materials.There are usually 2/4/6/8/10/12/18/24 movable carts inside based on different capacity.
Ⅱ.Air Source Heat Pump Drying Principle:
First, push carts with loaded fresh materials inside, then setting drying temperature, humidity and time. After hot air generated from heating system, anti-high temperature & humidity fans will circulate hot air across fresh materials laying on each tray of carts evenly inside drying room, humidity emitting fans start to work when the moisture reaches setting data. During drying process, when temperature reaches setting data, heat system will automatically shut down to achieve energy-saving effects. After well-drying, pull out carts containing dried materials. And prepare for next batch drying. Clients are suggested to have double quantity of carts to avoid energy waste during fresh materials loading time.
Ⅲ.Advantages Compared With Traditional Heat Pump Dryer:
- 01Plug-and-play Convenience: The dryer features an all-in-one design for easy and hassle-free operation.
- 02 Independent Operation: It operates independently without being affected by ambient temperature.
- 03 Versatile Application: Suitable for drying a wide range of fruits, vegetables, and materials below 80℃.
- 04 Customizable Options: Offers flexibility with customization choices such as plastic trays, stainless steel trays, and trolleys.
- 05 Durable and Hygienic Construction: Made from 304 stainless steel material, ensuring durability and hygiene.
- 06Automated Control: Equipped with automatic control for adjusting operation according to the set mode.
- 07Excellent Drying Performance: Achieves a stable and uniform temperature rise with minimal fluctuations, ensuring consistent and reliable drying results unaffected by human factors.
Technical Parameters
| Model | Length*width*height(mm) | Heat pump power (P) (Copeland compressor) |
Number of small carts (vehicles) |
Number of pallets (pcs) |
Number of fans (units) |
Pallet size 10 layers(mm) |
Approximate drying yield/ batch (kg) |
| 4 car side air supply | 4500*2300*2100 | 3 | 4 | 40 | 2 | 1400*900 | 1000 |
| 4 car rear air supply | 6000*1800*2500 | 7 | 4 | 40 | 4 | 1400*900 | 1000 |
| 6 car rear air supply | 6500*2300*2500 | 7 | 6 | 60 | 6 | 1400*900 | 1500 |
| 8 car rear air supply | 8000*2300*2500 | 7 | 8 | 80 | 6 | 1400*900 | 2000 |
| 10 car rear air supply | 7000*3300*2500 | 15 | 10 | 100 | 8 | 1400*900 | 2500 |
| 12 car rear air supply | 8000*3300*2500 | 15 | 12 | 120 | 8 | 1400*900 | 3000 |
| 18 car rear air supply | 8000*4800*2600 | 2*15 | 18 | 180 | 10 | 1400*900 | 4500 |
| 24 car rear air supply | 8000*6200*2600 | 2*15 | 24 | 240 | 12 | 1400*900 | 6000 |
| The above parameters are for reference only and the capacity is specific to pineapple to be dried. | |||||||
